INTERIOR LAMP NO. 4

CAV CIRCUIT FUNCTION

1 16DG INTERIOR LAMPS DRIVER

2 16BR GROUND

INTERIOR LAMP NO. 5

CAV CIRCUIT FUNCTION

1 16DG INTERIOR LAMPS DRIVER

2 16BR GROUND

INTERIOR LAMP-LEFT - BLACK

CAV CIRCUIT FUNCTION

1 16BR GROUND

2 16RD/YL FUSED B(+)

3 16BR/WT DOOR AJAR SWITCH SENSE

INTERIOR LAMP-MIDDLE FRONT

CAV CIRCUIT FUNCTION

1 16BR GROUND

2 16RD/YL FUSED B(+)

3 16BR/WT DOOR AJAR SWITCH SENSE

VA 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 45
