Fig. 8 2 PIECE PROPELLER SHAFT
1 - FLANGE BOLT 6 - NUT
2 - BEARING 7 - BRACKET
3 - PROPELLER SHAFT 8 - RETAINING BRACKET
4 - REAR AXLE 9 - COLLARED BOLT
5 - CABLE BRACKET 10 - TRANSMISSION
Fig. 9 3 PIECE PROPELLER SHAFT
1 - FLANGE BOLT 7 - BRACKET
2 - INTERMEDIATE BEARING 8 - RETAINING BRACKET
3 - CENTER SHAFT 9 - BOLT
4 - REAR SHAFT 10 - FRONT SHAFT
5 - REAR AXLE 11 - TRANSMISSION
6 - NUT
