8W-50 FRONT LIGHTING
Component Page
Beam Select Switch ..................8W-50-6
D+ Relay No. 1 ...........8W-50-7, 8, 12, 14, 15
Daytime Running Lamp Relay- Left Side . . 8W-50-7
Daytime Running Lamp Relay- Right
Side ..........................8W-50-6, 8
Daytime Running Lamps Relay ......8W-50-3, 13
Fog Lamp Relay ................8W-50-6, 9, 10
Fog Lamp Switch ....................8W-50-9
Fuse 1 ........................8W-50-3, 4, 13
Fuse 2 ..........................8W-50-6, 8
Fuse 3 ........................8W-50-6, 7, 12
Fuse 4 .......................8W-50-3, 14, 15
Fuse 5 ............................8W-50-9
Fuse 6 ............................8W-50-2
Fuse 9 ...................8W-50-12, 13, 14, 15
Fuse 10 ..........................8W-50-3, 4
Fuse 11 ........................8W-50-4, 7, 8
Fuse 12 ..........................8W-50-6, 8
Fuse 13 ........................8W-50-6, 7, 8
Fuse 14 .........................8W-50-6, 10
Fuse Block No. 1 ...............8W-50-2, 4, 5, 6
Fuse Block No. 2 .....8W-50-3, 7, 8, 12, 13, 14, 15
Fuse Block No. 3 ....................8W-50-9
G100 ...........................8W-50-7, 10
G102 ...........................8W-50-8, 10
G200 ..............................8W-50-2
G202 .............8W-50-7, 8, 10, 11, 13, 14, 15
G203 ..............................8W-50-9
Component Page
Hazard Warning Switch ...............8W-50-2
Headlamp Adjust Switch ..........8W-50-7, 8, 9
Headlamp Assembly-
Left .........8W-50-3, 4, 6, 7, 9, 10, 11, 13, 14
Headlamp Assembly-
Right ........8W-50-3, 4, 6, 8, 9, 10, 11, 13, 15
Headlamp Switch ................8W-50-4, 5, 6
Lamp Relay- Left ...............8W-50-3, 4, 14
Lamp Relay- Right ..............8W-50-3, 4, 15
Marker Lamp Connector ..............8W-50-11
Marker Lamp No. 1- Left Front ........8W-50-11
Marker Lamp No. 1- Right Front .......8W-50-11
Marker Lamp No. 2- Left Front ........8W-50-11
Marker Lamp No. 2- Right Front .......8W-50-11
Marker Lamp- Left Center ............8W-50-11
Marker Lamp- Left Rear .............8W-50-11
Marker Lamp- Right Center ...........8W-50-11
Marker Lamp- Right Rear ............8W-50-11
Multi- Function Switch ..........8W-50-2, 4, 5, 6
Power Distribution Center ............8W-50-12
Tail Lamp Assembly- Left .............8W-50-14
Tail Lamp Assembly- Right ...........8W-50-15
Turn Signal Relay ..................8W-50-2, 5
Turn Signal Switch .................8W-50-4, 5
Wiper/Turn Signal/Engine Start Control
Module ........................8W-50-2, 5
VA 8W-50 FRONT LIGHTING 8W - 50 - 1
