6. Rear cover refit.
•
fix the rear cover with the three screws.
•
Position the insulating terminal and
lock it with the relevant nut.
7. Fixing the pulley to the alternator shaft.
Use a box wrench and a bushing (Beta 720 type).
Locking torques (N*m)
Generator - Pulley 80
8. Lock the specific tool C in a vice.
Tighten the nut by turning the specific tool B.
Locking torques (N*m)
Generator shaft fixing nut: 110
9.
Remove the specific tools.
10. Make sure that the rotor turns freely.
PORTER 1.3 16V Electrical system
ES - 125
