Check the following:
1) Damage, 2) Damage or wear, 3) Damage, wear or deterioration,4) Wear 5) Cracking, damage or
flattening, 6) Damage, wear or deterioration, 7) Bending or damage, 8) Damage or wear, 9) Damage,
wear or deterioration.
Installation
1. Fix the leaf spring pad «A» and its stop «B» to
the leaf spring (in vans).
2. Temporarily fit the leaf spring on the chassis to-
gether with the elastic support and the nut.
3. Temporarily fit the leaf spring shackle with the
bushings and the nut.
4. Fix the elastic plate and the leaf spring buffer.
5. Fit the U-bolts and tighten the nuts.
Locking torques (N*m)
U-bolt - Leaf spring buffer 44 ÷ 54
Suspensions PORTER 1.3 16V
SS - 718
