21. Engine check bulb
22. Engine check bulb
23. Low fuel warning light
24. Beam
25. To the alternator (L)
26. 20A bulb
Fuel gauge
Check
Disconnect the fuel probe connector A placed at
the upper part of the fuel tank. Carry out the fol-
lowing checks on the receiving side end.
1. Disconnect the connector from the fuel level
probe cable harness. Earth the probe through a
check warning light.
2. Turn the ignition key switch to ON.
3. The check warning light turns on; after a few
seconds, the warning light must start flashing.
4. The fuel gauge must move up gradually.
KEY:
1. Battery
2. Link fuse
3. IG switch
4. Fuel gauge
5. Check warning light
6. Fuse
Electrical system PORTER 1.3 16V
ES - 160
