Connecting rod clearance measurement.
Measure the axial clearance between the connect-
ing rod and the crankshaft, with a thickness gauge.
If clearance exceeds the specified value, replace
the connecting rod or crankshaft, or both, if nec-
essary.
Characteristic
Axial clearance
Standard: 0.15 - 0.4 mm
Maximum: 0.45 mm
Connecting rod head width in the thrust direc-
tion
21.80 - 21.85 mm
Seat width on the connecting rod pin
22.0 - 22.2 mm
Coupling clearance measurement between the
connecting rod bushings and crankshaft
1. Temporarily fit the flywheel.
PORTER 1.3 16V Engine
EN - 305
