antee the control proper operation, by pressing the
control switch, the green transmission LED turns
on flashing, warning the user that it is necessary a
battery replacement.
CAUTION
TO PLACE THE NEW BATTERIES INSIDE THE REMOTE
CONTROL, REFER TO THE FIGURE. BATTERIES TO BE
USED ARE TYPE CR1616. THE USE OF DIFFERENT BAT-
TERIES FROM THOSE RECOMMENDED COULD CAUSE
IRREPARABLE DAMAGE TO THE REMOTE CONTROL. DO
NOT DISPOSE OF DISCHARGED BATTERIES IN THE EN-
VIRONMENT, USE THE APPROPRIATE CONTAINERS.
Characteristic
Battery type:
CR1616
ELECTRICAL CONTACTS FOR SLIDING
DOORS:
Contact maintenance:
The contacts of sliding doors allow the central
locking system to control locks from the doors.
Check the contact plate status periodically for
traces of dirt or oxide. To clean these devices, use
a cloth soaked in alcohol. Do not use abrasive ma-
terial.
SYSTEM PROTECTION FUSE:
Fuse replacement:
If the system stops working in manual mode as
well as in the radio operated mode, check if the
system protection fuse A is in proper conditions.
For this check, it is necessary to remove the fuse
box board, located under the instrument panel
close to the pedal assembly, removing the two fix-
ing screws.
Modello GEMINI
ALARM SYSTEM AND CENTRAL LOCKING
GEMINI 7563 MODEL
Introduction
The unit 7563 is a module operated by radio comprising a self-powered alarm control unit and an
external sound unit, that can be used on vehicles without original radio control and a 12V battery.
Electrical system PORTER 1.3 16V
ES - 132
