3. Lift section B so as to detach section D.
(Pay attention not to scratch the instrument panel
with the clip of section C).
4. Detach the fitting of section E.
5. Remove the object-holding drawer/glove-box
compartment and the relevant lid by taking out the
seven screws.
Instrument panel removal
1. Lift the cover using a plain slot screwdriver wrapped around with a cloth, then remove the brake fluid
reservoir inspection cover.
Pay attention so as not to scratch during removal.
2. Remove the brake fluid reservoir by taking out
the two bolts.
3. Remove the instrument panel by taking out the
seven bolts.
PORTER 1.3 16V Chassis
CH - 781
