4. Support
5. Spacer
6. Tap roller bearing
7. Nut
8. Washer
9.Pinion connection flange
10. Oil seal
11. Tap roller bearing
12. Spacer
13. Spacer
14. Pinion
15. Tap roller bearing
16. Tap roller bearing
17. Tap roller bearing
18.Spacer
19. Differential housing
20. Tap roller bearing
21. Screw
22. Crown gear
23. Bevel gear pair support
24. Pin
25. Crown wheel shaft
26. Crown wheels
27. Side pinions
28. Spacer
29. Spacer
30. Plate
31. Gasket
32. Cap
Adjustment procedure
1. Adjusting control pinion protrusion
2. Measuring control pinion bearing preloading
Characteristic
Specified value:
102.5 - 141.7 Nm
(When the oil seal is fitted)
3. Differential housing assembly
Differential PORTER 1.3 16V
DI - 602
