Removal - Refitting timing pulley
Camshaft pulley removal
1. Remove the timing belt.
2. Remove the cylinder head cover.
3. Camshaft pulley removal. Using a special tool,
prevent the camshaft pulley from rotating, then un-
do the three pulley fixing screws. Then, remove the
camshaft pulley.
Specific tooling
020172Y TOOL TO LOCK THE TIMING BELT
PULLEY
Camshaft pulley check
1. Measure the pulley outside diameter with a
gauge.
Characteristic
Timing shaft pulley wear limit
119.8
If the value measured is lower than the specified value, replace the pulley.
2. Visually check that the timing belt pulley is not
damaged. Replace, if necessary.
PORTER 1.3 16V Engine
EN - 243
