installing sensor 7059 under the cab panelling,
and therefore it is completely out of sight.
THE SENSOR MUST BE ALWAYS FIXED AT A CENTRAL
POSITION WITH RESPECT TO THE VEHICLE AXIS, WITH
THE SIDE SHOWING THE WORDS AND THE ADJUST-
MENT TRIMMER FACING THE VEHICLE INTERNAL
SPACE.
KEY:
1. Sensitivity adjustment
2. Alarm indicator LED
Super-high frequency sensor adjustment
In case you do not wish to activate the diagnosis, proceed as described below:
•
Adjust the trimmer to a maximum sensitivity position (turning it clockwise to maximum).
•
Activate the alarm and wait for the end of neutral activation time with doors, bonnet, trunk
and windows of the vehicle closed.
•
Move the hands close to the vehicle windows (side windows, windshield and rear window)
checking that the sensor 7059 does not detect anything.
•
If alarm conditions are detected, it is necessary to reduce the sensor sensitivity. Turn the
adjustment trimmer anticlockwise, then repeat the test as indicated above.
•
If sensor operations are not detected, deactivate the alarm and lower one of the front win-
dows of the vehicle.
•
Activate the alarm again and introduce a foreign matter inside the cab, simulating a theft
attempt.
•
If the alarm intervenes only after the introduction of the foreign body in the cab, adjustment
has been carried out correctly.
Diagnosis
ACTIVATING THE DIAGNOSIS PROCEDURE THE ALARM RETURNS TO THE INITIAL STATUS,
AS PROGRAMMED BY GEMINI. THEREFORE, CARRY OUT A POSSIBLE DIAGNOSIS TEST BE-
FORE PROGRAMMING OR CHANGING THE PIN-CODE (SEE THE USER MANUAL). TRANSMIT-
TERS, ELECTRONIC KEYS, TAG CARDS, MAGNETIC CONTACTS AND INFRARED SENSORS
PREVIOUSLY STORED ARE NOT DELETED.
For a correct check of connections, sensors or control peripherals, turn off any TAG cards near the
vehicle on which the test is being carried out.
In fact, the TAG periodic transmission could distort the different tests.
To activate the procedure, follow the instructions given below:
•
Remove the alarm power supply.
•
Press and hold the LED status key or short-circuit the RED and BLACK cables of the two-
way connector to connect the LED.
•
Power the alarm.
•
Once the alarm is powered, the 4 sound alarms and 4 turn indicator flashes, indicate that
"diagnosis" has started.
