7. Fit the support dust guard.
8. Align the spring end with the concave section of
the upper seat F and lower seat G. Remove tool
H.
Installation
Fit the suspension support. (Use new nuts)
Locking torques (N*m)
Front suspension support for chassis 35 - 44 Nm
Steering articulation fitting
1. Fit the steering articulation on the lower support
of the shock absorber.
2. Fit the new bolts and screws in the relevant
seats and tighten them temporarily.
3. Connect the brake hose to the calliper.
4. Fit the clip locking the pipes on the shock ab-
sorber.
5. Bleed the air completely.
6. Move the vehicle, without load, upwards and
downwards, so that the suspension settles.
7. Tighten the following:
Bolt and nut (Shock absorber for steering articu-
lation)
Locking torques (N*m)
Steering joint - Front shock absorber 78.5 ÷ 98
Suspensions PORTER 1.3 16V
SS - 692
