10. Fit the oil pressure switch on the oil pump.
11. Connect the engine cable harness connector
to the oil pressure switch.
12. Start up the engine and check any oil leaks.
- USE A LONG HEXAGONAL BOX-SPANNER TO FIT THE
OIL PRESSURE SWITCH.
- THE NEW OIL PRESSURE SWITCH IS COATED WITH
SEALANT.
- NEVERTHELESS, WHEN REPLACING THE OIL PRES-
SURE SWITCH WITH A NEW ONE, REMOVE THE SEALANT
COMPLETELY BEFORE WRAPPING THE SEALING TAPE .
- MAKE SURE TO CLEAN THE OIL PUMP SIDE HOLE
THREADS BEFORE FITTING THE OIL PRESSURE
SWITCH.
Locking torques (N*m)
Oil pressure switch - Cylinder block 12÷20
Removal
1. Place the engine unit on a suitable service
stand.
2. Remove the oil filtering element.
3. Remove bolts and nuts fixing the oil sump.
4. Separate the oil sump from the cylinder block.
5. Remove the oil filter undoing the fixing bolts.
6. Remove all the bolts fixing the oil pump unit.
7. Remove the oil pump from the cylinder block.
Engine PORTER 1.3 16V
EN - 350
