Inspection
Check the following parts. Replace any faulty
parts.
1. Front axle bearing replacement
•
With a press, remove the wheel shaft
from the steering articulation.
•
Move the collar, as shown in the figure.
Remove the bearing by pushing the
collar.
2. Front axle bearing installation
•
Place the internal radial ball bearing
using the following tool:
N.B.
- MAKE SURE THAT THE BEARING IS IN CONTACT WITH
THE STOP SECTION OF THE STEERING ARTICULATION.
Specific tooling
020188y Axial hub support and driving pinion
tool series - Front axle bearing and differential
pinion replacement kit
Suspensions PORTER 1.3 16V
SS - 702
