11. Fit the diffuser hand grip with the relevant
screw.
12. Connect the speedometer and electric con-
nections.
13. Fit the instrument panel and the warning lights
with the five screws.
14. Fit instrument panel upholstery frame.
15. Fit the steering wheel (see the "Steering" sec-
tion).
16. Connect the battery negative terminal.
Installation
Refitting air vents/loudspeakers/cigarette
lighter
1. Fit the cigarette lighter support bracket with the
two screws.
2. Fit the loudspeakers with the two screws.
3. Fit the right and left side resistors with the four
screws.
4. Fit the central and left air vents with the three
screws.
5. Fit the air vent and, afterwards, place the clip.
6. Fit the diffuser assembly by tightening the five
screws.
Chassis PORTER 1.3 16V
CH - 786
