Wiper switch
Rear windscreen wiper and spray nozzle
switch
TERMINALS:
0= Windshield washer spray WASH2
1= Windscreen wiper first position
2= Windshield washer spray WASH1
TERMINALS:
1= From the spray nozzle motor
2= To ground
3= To ground
4= From the windscreen wiper motor
Make sure there is continuity between the relevant terminals as indicated in the following table.
Continuity table
A= Switch
B= Terminal
Interruttore luci stop
Check
1. Disconnect the stop light switch.
2. Make sure there is continuity between terminals
when the brake pedal is pushed.
3. Make sure there is no continuity between termi-
nals when the brake pedal is not pushed.
Electrical system PORTER 1.3 16V
ES - 88
