Initial operations
Alternator removal
1. Remove the connector and cable on the alter-
nator rear side.
2. Remove the alternator with belt tension adjust-
ment bar.
Remove the driving belt.
Removal of the engine wire from the cylinder
head
•
Disconnect the engine wire connector
from the following parts:
1. Ignition coil
2. Injectors
3. Pressure sensor
4. Throttle sensor
5. Intake air temperature sensor
6. VSV (Vacuum Switching Valve) - idle speed
7. Engine coolant temperature sensor
8. Oxygen sensor
9. Camshaft sensor
10. VSV (Vacuum Switching Valve) - bleeding
11. Ignition system
12- VSV (Vacuum Switching Valve) EGR (Recir-
culation of Exhaust Fumes)
13. Ground lead
14.Oil pressure switch
15. Handbrake switch
•
Disconnect the cable terminals.
•
Remove the engine wires from the cyl-
inder head.
Engine PORTER 1.3 16V
EN - 256
