Tightening torques
ENGINE
Name Torque in Nm
Cylinder head - Water outlet joint 15÷22
Cylinder head - Water temperature sensor 24.5 ÷ 34.3
Water pipe - Radiator electric fan thermal switch 20÷30
Cylinder block - Water pump 15 ÷ 22
Cylinder block - Water inlet joint 6 ÷ 9
Catalytic converter - Muffler 39 ÷ 54
Exhaust pipe - Catalytic converter 42 ÷ 56
Exhaust manifold - Front exhaust pipe 42÷62
0X1 Oxygen sensor - Exhaust manifold 29.4 ÷ 39.2
0X2 Oxygen sensor - Exhaust manifold 29.4 ÷ 39.2
Oxygen sensor - Exhaust manifold 29÷39
Cylinder head - Exhaust manifold 35 ÷ 53
Cylinder head - Inlet manifold 15 ÷ 22
Inlet manifold - Fuel delivery pipe 6÷11
Inlet manifold - EGR pipe 15÷22
Inlet manifold - EGR valve 15÷22
EGR valve - EGR pipe 47÷71
Inlet manifold - Throttle body 15÷22
Fuel tank - Canister bleed valve bracket 3.9 ÷ 6.9
Camshaft sensor - Cylinder head 15÷22
Oil sump - Cylinder block 7÷12
Oil filter - Cylinder block 15÷22
Oil pump - Cylinder block 6÷9
Cover - Oil pump 8÷13
Oil pressure switch - Cylinder block 12÷20
Oil sump - Cylinder block 7÷12
Oil pump body - Oil pump cover 8÷13
Oil pump - Oil pressure switch 12÷20
Intake pipe for oil in sump - Oil sump 15 - 22
Cylinder block - Oil pump 6÷9
Clutch cover 15÷22
Connecting rod - Connecting rod cap 34÷44
Engine shaft - Camshaft control belt pulley 15÷22
Crankshaft - Crankshaft belt pulley 88÷98
Crankshaft - Flywheel 78÷98
Cylinder block - Rear bottom plate 10÷15
Cylinder block - Generator bracket 34÷49
Cylinder block - Transmission 49÷69
Cylinder block - Rear oil seal ring 6÷9
Cylinder block - Main bearing cap 44 ÷ 54
Cylinder head - Cylinder block 59÷67
Cylinder head - M 8 Camshaft 13÷17
Cylinder head - M 10 Camshaft 29÷36
Cylinder head - Cylinder head cover 9 ÷ 13
Cylinder head - Spark plug 15 ÷ 22
Valve adjustment lock nut 17 ÷ 22
Timing system pulley screws 15÷22
Crankshaft - timing system pulley screw 88 ÷ 98
Timing system belt tensioner 29÷44
Crankshaft pulley - transmission screws 20÷29
Timing belt cover screw 2÷4
Cylinder head cover - Ignition coil 6÷11
Generator fixing screws - M8 18÷22
Generator fixing screws - M10 28÷32
Fuel filter fixing nut 34 ÷ 43
Cover - Thermostat 5.9 ÷ 8.8
Radiator - Water thermal switch 24.5 ± 5
Generator shaft fixing nut: 110
Generator - Pulley 80
PORTER 1.3 16V Characteristics
CH - 27
