IN ORDER TO CARRY OUT THE DIFFERENT FITTING PROCEDURES PROPERLY, CAREFULLY
CHECK ALL THE ELECTRICAL CONNECTIONS REQUIRED, PAYING SPECIAL ATTENTION TO
BASIC CONNECTIONS:
•
DEVICE POWER SUPPLY (POSITIVE AND GROUND).
•
LIVE POSITIVE (+15/54)
•
DOOR SWITCH.
•
BONNET OR TRUNK SWITCH.
Functions
•
Alarm system activation/deactivation through rolling code radio remote controls (random
rolling code).
•
Passive activation function (programmable).
•
Visual signalling (blinker).
•
Sound alarms (programmable).
•
Perimetric protection.
•
Volumetric protection (excludible during the activation phase).
•
Central locking, electric windows and roof (for vehicles equipped with "Pack-comfort" sys-
tem).
•
Engine electrical locking.
•
Current absorption sensor (programmable).
•
Alarm memory by means of visual signalling/sound alarms.
•
"PANIC" or "CAR-FINDER" function.
•
Emergency deactivation of the system through the pin-code.
•
Negative control for additional, self-powered siren and pager.
•
Anti-hijack function.
•
Garage function.
GEMINI 7563.01: Similar to 7563 without electronic key.
GEMINI 7562: Similar to 7563 but not self-powered.
GEMINI 7562.01: Similar to 7562 without electronic key.
GEMINI 7561: Similar to 7562.01 without engine block and control for additional or self-powered siren.
OPERATION DESCRIPTION
1. Alarm total activation
Press key No. 1 (stippled) of the radio control or insert the electronic key in the appropriate hole.
A sound alarm by the siren and a visual signal by the turn indicators confirm the operation.
The alarm has a pre-activation "neutral period" which lasts 45". During the first 25" of this period, the
sensors can be excluded as described in the relevant section.
2. Activation without siren sound
This function allows users to activate the alarm system without the siren sound in case of a car break-
in is attempted.
To exclude the siren, follow the instructions given below:
PORTER 1.3 16V Electrical system
ES - 133
