Remove the plastic protection manually and after-
wards unscrew the pressure relief valve and the
check valve.
Unscrew the solenoid of the solenoid valve to
check the jack descent acting on the knob as
shown in the figure.
Finally, remove the valve body by acting on the nut
indicated in the figure.
Montaggio valvole
Valve body fitting
Before refitting the valve body, it is necessary to clean all the ducts thoroughly.
Wash with mild solvents and afterwards blow with compressed air.
Place the valve body in its seat located in the valve body and tighten to the prescribed torque.
Locking torques (N*m)
valve body for valve body 25 - 30 Nm
Fit the solenoid in the seat located in the solenoid
valve and tighten to the prescribed torque.
Locking torques (N*m)
Solenoid for valve body 5 - 6 Nm
Tipper version PORTER 1.3 16V
VR - 734
