6. Fit the rear wheel.

7. Lower the vehicle. Move the vehicle rear sus-

pension, upwards and downwards, two or three

times to stabilise suspension.

8. With the vehicle unloaded, tighten the following

sections:

•

Elastic pin support side nut

•

Leaf spring subassembly upper and lower section nut

Locking torques (N*m)

Spring support pin - Leaf spring assembly. 88 ÷ 108

•

Leaf spring shackle support nut.

Shock-absorbers removal

PORTER 1.3 16V Suspensions

SS - 719
