PIAGGIO PORTER 1.3 16V 2008 User Manual

Characteristic
Resistance:
10 Ω . or less
Voltage:
battery voltage
Codici diagnotici
Failure code diagram specifications
SPECIFIED CODES OF THE ISO/SAE STANDARDS
For further information related to single codes, refer to the failure code diagram.
Diagnostic failure code: P0105
Failure detected:Manifold absolute pressure/ barometric pressure circuit malfunction
Affected area
- Interrupted or short-circuited cable in the manifold absolute pressure sensor
- Manifold absolute pressure sensor
- Engine electronic control unit (ECU)
Diagnostic failure code: P0110
Failure detected:Intake air temperature circuit failure
Affected area
- Interrupted or short-circuited cable in the intake air temperature sensor
- Intake air temperature sensor
- Engine electronic control unit
Diagnostic failure code: P0115
Failure detected:Engine coolant temperature circuit failure
Affected area
- Interrupted or short-circuited cable in the water temperature sensor circuit
- Engine coolant temperature sensor
- Engine electronic control unit
Diagnostic failure code: P0116
Failure detected: Engine coolant temperature/functional problems
Affected area
- Engine coolant temperature sensor
- Cooling system
Diagnostic failure code: P0120
Failure detected:Throttle switch circuit/pedal position sensor/switch "A" failure
Affected area
- Interrupted or short-circuited wire in the throttle position sensor circuit
- Throttle position sensor
Iniection System PORTER 1.3 16V
IS - 414
