Rear window
Rear window upholstery panel
TOOLS AND OTHER EQUIPMENT
Butyl tape To prevent water infiltration
MP grease To lubricate
Water with soap For a better gasket sliding
Brush, etc. To apply the water with soap
Wooden hammer To fit the support
Paint for touch-up For paint touch-ups after removal/fitting and adjustment
COMPONENTS
1. Rear window upholstery panel
Removal/Fitting
REMOVAL
Remove the rear window internal upholstery panel
using the special tool to take out the relevant re-
tainers.
COMPONENTS:
2. Panel
3. Retainer
FITTING
Fit the rear window internal upholstery panel.
Rear window
COMPONENTS:
1. Rear window protection strip
2. Window and sealing gasket
Chassis PORTER 1.3 16V
CH - 744
