PIAGGIO PORTER 1.3 16V 2008 User Manual

Thrust bearing
1. Check that the thrust bearing turns freely, with-
out jamming. Turn the thrust bearing while an axial
force is manually applied to the this bearing. Make
sure there are no abnormal signs of hardening or
obstacles.
2. Check the thrust bearing hub for signs of dam-
age or wear. Also check the contact surface of the
relevant stop and housing sliding section for signs
of damage or wear.
Thrust bearing hub stop
Check for wear or damage.
Pedale frizione
Removal
Remove the parts, following the numerical order shown in the figure.
Components:
PORTER 1.3 16V Engine
EN - 345
