Fit this assembly with part 66 interposed. Components 67 to 71 are generally used as a set.
70. Gasket
71. Rpm indicator guide gear subassembly
Fit this gasket in the external groove of part 69. Made of nylon.
Gear oil
Filling capacity: 1.0 ± 1.1 litres
Place the vehicle on level ground and fill with oil up to the lower edge of cap 61. SAE 75W-90 or 80W-
go API GL-3.
72. T oil seal
During the fitting phase, strictly observe the protrusion size, which shall be of 5 ± 0.3 mm.
73. K Oil seal
The gasket inclination, at the time of positioning it in the seat by pressure, shall be of 1° or less. Apply
MP grease onto the lip section.
74. Oil guide plate
This plate is fitted inside the gearbox.
Tightening torque: 6.9 - 9.8 Nm
Repairs to be carried out on the vehicle
1. Sleeve assembly of the rpm indicator gear.
2. Box gasket and cover.
3. Oil deflection and bearing locking.
4. Control gear of the rpm indicator, radial bearing and the oil drainage screw.
5. Check that there is continuity between the reverse gear light switch and engagement of the reverse
gear.
Removal
Recommendations before removal
This section has a summary of the gear main components illustrated in the sections:
•
Component Gear (Part 1)
•
Component Gear (Part 2)
•
Input shaft
•
Secondary shaft
The description facilitates the removal and fitting operations. For clearer and further details, refer to the
corresponding pages.
PORTER 1.3 16V Gear-box
GE - 557
