Read the category of the main journal
on the crankshaft.
Main journal categories
5 = categories of the main journal No.5 (FLYWHEEL SIDE)
4 = categories of the main journal No.4
3 = categories of the main journal No.3
2 = categories of the main journal No.2
1 = categories of the main journal No.1 (TIMING SIDE)
•
Set the category of main bushings, us-
ing the table shown below.
M = Crankshaft
N = Main journal category
O = Cylinder block
N = Main bearing category
3. Connecting rod bushing selection
•
Read the category of the connecting
rod pin.
Connecting rod pin category
1 = Category of the connecting rod pin No.1 (TIMING SIDE)
2 = Category of the connecting rod pin No.2
3 = Category of the connecting rod pin No.3
Engine PORTER 1.3 16V
EN - 320
