Adjustment tolerance
~ ± 2 mm
Thickness height:
1 mm
Adjustment of height difference
1. The adjustment is carried out after loosening the
lower roller fixing bolt.
Characteristic
Adjustment tolerance
~ ± 2 mm
2. The adjustment is carried out after loosening the
screw fixing the lock striker plate.
IF THE DOOR REAR SECTION IS LOWERED OR LIFTED,
NEVER TRY TO CORRECT THE TRIM BY OPERATING ON
THE DOOR LOCKING PLATE. ADJUST BY OPERATING ON
ITS HINGE.
Characteristic
Adjustment tolerance
~ ± 2 mm
3. Move the lower catch at a distance equal to the
movement.
- Temporarily fit the door by tightening the bolts
fixing the lower catch.
- After opening/closing the door two or three times,
tighten the bolts tightly.
Chassis PORTER 1.3 16V
CH - 768
