KEY:
1. Arm and blade
2. Connection unit
3. Motor
4. Windscreen wiper
Rear wiper mechanism
KEY:
1. Nut
2.Rear window wiper blade and arm
3. Connection cover
4. Hexagon nut
5. Washer
6. Connection gasket
7. Motor unit
Electrical system PORTER 1.3 16V
ES - 94
