PIAGGIO PORTER 1.3 16V 2008 User Manual

Oil sump removal
1 Loosen the screws and nuts fixing the oil sump,
operating in two or three stages. Take out bolts
and nuts.
2 Separate the oil sump from the cylinder block
with the following special tool:
Specific tooling
020403Y FLYWHEEL LOCK WRENCH
3. Remove the two oil sump gaskets.
4. Remove the rear flange with the sealing ring.
PORTER 1.3 16V Engine
EN - 295
