Cab roof cable harness (mirror courtesy light)

1. To the instrument panel cable harness

2. Internal lighting

POSITIONS OF CABLES IN THE CONNECTORS - CONNECTOR FRONT SIDE VIEWS

From A

Position Terminal Terminal Position

Light fuse (L) C2 C1 Courtesy light (+)

Courtesy light (DOOR) D1 D2 Courtesy light switch (+)

Electrical system PORTER 1.3 16V

ES - 184
