Parking brake
PARKING BRAKE
Code
Action
Duration
1
465021
PARKING BRAKE CONTROL LEV-
ER - REPLACEMENT
2
465721
PARKING BRAKE FRONT CABLE
REPLACEMENT
3
465731
PARKING BRAKE REAR CABLE
REPLACEMENT
PORTER 1.3 16V
Time-sheet
TS - 841
840
842
