Adjustment in longitudinal direction of the up-
per section
Adjust after undoing the body side hinge bolts.
- When the upper section is adjusted in longitudinal direction,
make sure that the distance between the rear window support
side surface and the door side surface does not exceed 4.6 -
8.6 mm.
- Considering the adjustment, that shall not exceed 2.0 mm,
loosen the door side hinge bolts.
Adjustment in longitudinal direction of the low-
er section and closing adj.
Carry out adjustments by changing the fitting po-
sition of the lock plate.
Front bumper
COMPONENTS:
1. Screws
2. Bumpers
PORTER 1.3 16V Chassis
CH - 773
