5. Fit the rear axle shaft together with the shoe
holding plate, using the following special tool.
Specific tooling
020226y Rear axle shaft extractor
6. Fasten the shoe holding plate with four nuts.
Locking torques (N*m)
Shoe holding plate - Rear axle shaft housing
63.7 ÷ 70.4
7. Insert the brake hose fitting nut.
8. Fit the hand brake cable end.
9. Fit the hand brake cable adjustment nut.
10. Bleed the air completely.
11. Adjust the brake shoe clearance.
12. Restore the oil level in the differential.
13. Fit the wheel.
14. Lower the vehicle.
Locking torques (N*m)
Brake pipe joint - Brake cylinder 10 ÷ 12
PORTER 1.3 16V Suspensions
SS - 715
