PIAGGIO PORTER 1.3 16V 2008 User Manual

Pannelli
Components
1. Door inside handle and relevant circlip
2. Circlip and spacer
3. Window lifter handle
4. Sliding door upholstery panel
Sliding door upholstery panel
TOOLS AND OTHER EQUIPMENT
Butyl tape To prevent water infiltration
MP grease To lubricate
Water with soap For a better gasket sliding
Brush, etc. To apply the water with soap
Wooden hammer To fit the support
Paint for touch-up For paint touch-ups after removal/fitting and adjustment
Upholstery panel removal
1. Using a cloth, remove the circlip and take out
the door internal handle.
2. Using a cloth, remove the circlip and take out
the window lifter handle and collect the relevant
spacer.
PORTER 1.3 16V Chassis
CH - 755
