Windscreen
Preparation
Tools and other equipment:
- Cable to work with (about 5 mm x 6 m): used to fit glass
- Bamboo spatula: used to fit glass
- Rubber hammer: used to fit glass
- Brush, etc.: used to apply water with soap
- Water with soap: used to fit glass easily
COMPONENTS:
1. Front wiper arm and brush
2. Windshield and sealing gasket
Removal
Removal (to be carried out by two individuals)
1. With a bamboo spatula (or with a plain slot
screwdriver, etc.) take out the sealing gasket from
the body by pressing on the edge.
This operation shall be carried out from inside the
cab.
2. Take out the windshield by pressing and, while levering from the inside, lift the upper part of the
sealing gasket from both ends.
Remove the windshield with the sealing gasket.
Chassis PORTER 1.3 16V
CH - 740
