CLUTCH
Specification Desc./Quantity
Engine - transmission mechanism Engine - clutch - transmission
Type Dry single disc
TRANSMISSION
Specification Desc./Quantity
Forward gear Continue drive gear
Reverse gear With sliding gears
First gear Ratio 3.769
Second gear Ratio 2.045
Third gear Ratio 1.376
Fourth gear Ratio 1.000 (-)
Fifth gear Ratio 0.838
Reverse gear Ratio 4.128
Reducer ratio 1.23 (27/22)
DIFFERENTIAL UNIT
Specification Desc./Quantity
Bevel gear pair Crown / Pinion
Gear ratio 4.444 (40/9)
WHEEL ADJUSTMENT
Specification
Desc./Quantity
Toe-in 2.0 +1.5 / -1.0 mm
Camber 1°23' + 40' / - 50' (Deck)
1°00' + 40' / - 50' (Van)
Caster angle 3°13' ± 1° (Deck)
3°02' ± 1° (Van)
Kingpin inclination angle 10°49' ± 1° (Deck)
11°25' ± 1° (Van)
Rear axle Semi-floating
STEERING
Specification
Desc./Quantity
Wheel outside diameter (mm) 370
Steering wheel turns 4.1
Steering Housing gear Pinion and rack
Internal steering angle (°) 36.0
External steering angle (°) 34.8
BRAKE
Specification
Desc./Quantity
Front brake disc brake
Rear brake drum brake
Main brake cylinder (mm) Inside diameter 19.05
Front wheel brake cylinder (mm) Inside diameter 51.10
Rear brake cylinder (mm) Inside diameter ø 17.46
Parking brake Mechanical functioning acting on the rear wheels.
SUSPENSION
Specification
Desc./Quantity
Front suspension Independent, McPherson type, with suspension arms and
struts fitted on silent-block.
Rear suspension Rigid semifloating axle.
Front shock absorber spring Helicoidal type
Rear shock absorber spring semi-elliptical leaf spring
Shock absorber Telescopic double-acting
Characteristics PORTER 1.3 16V
CH - 24
