PIAGGIO PORTER 1.3 16V 2008 User Manual

Installation
1. Fit the door on the body.
2. Connect the heated rear window device (if fit-
ted).
3. Tighten the door hinge nuts.
4. Fit the side shock absorbers by tightening the
two relevant bolts.
5. Align the door with respect to the body.
Locking torques (N*m)
Tail door support - Tail door 17.7 ÷ 23.5
Rear door panel
Rear door upholstery panel
COMPONENTS:
1. Rear upholstery panel
Removal/Fitting
REMOVAL
1. Remove the door upholstery panel using the special tool to take out the relevant retainers.
FITTING
1. Fit the door upholstery panel.
Chassis PORTER 1.3 16V
CH - 770
