PIAGGIO PORTER 1.3 16V 2008 User Manual

Engine type 2
Engine mechanism
E.G.R. circuit intake duct
Inlet manifold removal
THE INLET MANIFOLD CAN BE REMOVED TO-
GETHER WITH THE THROTTLE BODY, EGR
VALVE, EGR MODULATOR AND INJECTORS,
IF NECESSARY.
1. Detach the suction pipe from the throttle body.
2. Remove the bolts and fixing nuts on the EGR
valve and on the EGR vacuum modulator.
3. Remove the bolts and fixing nuts on the throttle body and gasket.
KEY:
A= Throttle body
B= Gasket
PORTER 1.3 16V Engine
EN - 225
