18. Ignition coil 2
From A
Position Terminal Terminal Position
Instrument panel cable har-
ness (Instrument panel, oil
pressure warning light)
H5 H6 Low oil pressure switch
Handbrake switch engaged
(+)
G7 G9 To the instrument panel cable
harness (Instrument panel,
handbrake warning light en-
gaged)
Connection to N5-N13 - N75 Ignition coil 2 (IG+)
Ignition coil 2 (-) N77 N56 EFI ECU (IG2)
Ignition coil 1 (IG +) N5 N31 To the instrument panel cable
harness (J/B fuse) B
Ignition coil 1 (-) N7 N27 EFI ECU(IG1)
Cam sensor (NE-) N47 N48 EFI ECU (N-)
Cam sensor (NE+) N8 N26 EFI ECU (N+)
EFI ECU(OX) X27 X28 Lambda probe (+)
EFI ECU (THW) X29 X30 Water temperature sensor (+)
Water temperature sensor (-) X31 - Connection to X35-X34
EFI ECU (THA) X32 X33 Intake air temperature sensor
(+)
EFI ECU (E2) X35 X34 Intake air temperature sensor
(-)
Connection to X38-X46 - X40 Throttle sensor (VC)
EFI ECU (VC) X38 X46 Pressure sensor (VC)
EFI ECU (PIM) X43 X45 Pressure sensor (PIM)
Connection to Z48-Z49 (near
X44)
- X44 Pressure sensor E1
Connection to X97-X100 - X50 Injector No. 1 (+)
EFI ECU (#10) X56 X51 Injector No. 1 (-)
Connection to X97-X100 - X52 Injector No. 2 (+)
Connection to X96-X98 - X53 Injector No. 2 (-)
Connection to X97-X100 - X54 Injector No. 3 (+)
Connection to X56-X51 - X55 Injector No. 3 (-)
EFI ECU (#20) X96 X98 Injector No. 4 (-)
Electrical system PORTER 1.3 16V
ES - 176
