Remove the parts, following the numerical order shown in the figure.
KEY:
1. Cotter pin
2. Pin
3. Nut
4. Screw
5. Bracket
6. Pipe clamp
7. Brake pipe fitting nut
8. Screw
9. Screw
10. Brake pump assembly with power brake
11. Nut
12. Main cylinder assembly
13. Sealing ring
Brake booster inspection procedure
Power brake hermetic seal check
Start the engine. Stop it after running it for one or two minutes. Push the brake pedal for several times,
applying force necessary during regular braking. If during the second or third time the brake is pushed,
its position lifts gradually, it means that the power brake works properly.
Braking system PORTER 1.3 16V
BS - 618
