1. Disconnect the hose.
2. Remove the castle nut with the special tool A.
Specific tooling
020221y Brake drum stop device
3. Remove the hub and the disc, with the special
tool B.
Specific tooling
020222y Front hub and drum extractor
Front disc brake calliper
Removal
Removal
Remove the parts, following the numerical order illustrated.
PORTER 1.3 16V Braking system
BS - 625
