Front hubs removal
Removal
1. Lift the vehicle with the jack
2. Remove the front wheel.
N.B.
- MAKE SURE THAT THE JACK IS PLACED CORRECTLY,
MATCHING THE LIFTING POINTS.
5. Disc assembly removal
•
Remove the cotter pin
•
Remove the castle nut using the fol-
lowing tool:
6. Remove the disc brake assembly using the fol-
lowing tool:
Specific tooling
020221y Brake drum stop device
0.20222y Front hub and drum extractor
3. Disconnect the brake hose from the calliper.
4. Remove the calliper assembly by unscrewing
the two bolts.
N.B.
- COVER THE BRAKE HOSE CONNECTION WITH A CLOTH
TO KEEP DUST FROM ENTERING.
PORTER 1.3 16V Suspensions
SS - 699
