2. Make sure that the belt remains locked when the
inclination angle is exceeds the 45 degrees.
Never remove the winder.
Fitting the front seat internal bolt
Fit the front seat internal bolt assembly in the cor-
rect fitting position as shown in the figure.
KEY:
A. Left
B. Right
Safety belts
FRONT
Safety belt at three anchor points without winder
KEY:
1. Bolt
2. Bolt
3. Safety belt
4. Safety belt attachment
Safety belt at three anchor points with winder
KEY:
1. Bolt
2. Bolt
3. Screw
4. Safety belt
5. Safety belt attachment
PORTER 1.3 16V Chassis
CH - 791
