5. Jump terminals T and E of the connector using
the following specific tool.
Specific tooling
Integrated in the 020618Y Lift for diagnosis
6. With a stroboscopic light, check that the ignition
timing reference on the flywheel matches the rear
plate reference.
- IGNITION TIMING SHOULD BE CHECKED OR ADJUSTED
USUALLY AFTER THE ENGINE IS FULLY HEATED.
Characteristic
Ignition timing:
Before Top Dead Centre 3 ± 2°/minimum
7. If the ignition timing reference is not aligned with
the indicator, adjust the ignition timing by turning
the camshaft sensor
- TURN THE CAMSHAFT SENSOR CLOCKWISE TO AD-
VANCE TIMING.
Locking torques (N*m)
Camshaft sensor - Cylinder head 15÷22
ECU - Centralina elettronica
Electronic injection control unit
1. Check if the diagnostic system indicates the fail-
ure codes.
Electrical system PORTER 1.3 16V
ES - 168
