7. Turn the rotor by hand. Make sure that the rotor
turns slowly. Otherwise, service the oil pump.
Installation
1. Remove the gasket from the oil pump and from
the cylinder block.
2. Apply sealant onto the fitting surface of the cyl-
inder block oil pump, as indicated in the figure.
Recommended products
Three Bond 1207C SEALANT
-
3. Apply engine oil onto the oil seal internal sur-
face.
4. Replace the O-ring A of the oil pump with a new
one.
5. Fit the oil pump on the cylinder block with fixing
bolts
CAUTION
- BE CAREFUL NOT TO DAMAGE THE CRANKSHAFT OIL
SEAL DURING THE OIL PUMP FITTING.
- BE CAREFUL NOT TO LET THE O-RING FALL DURING
THE OIL PUMP FITTING.
Locking torques (N*m)
Oil pump - Cylinder block 6÷9
PORTER 1.3 16V Engine
EN - 355
