3. Selection pin cover
4. Rear cover
Sub-gear
1. Each single sub-gear has one tooth less with
respect to the main gear; in this way, a phase
movement towards the main gear can be obtained.
This makes possible to remove clearance among
the teeth at the moment of meshing with the main
gear. In addition to this, an elastic spring (conical)
placed between the sub-gear and the main gear
avoids any noise when shifting gears.
2. The sub-gear is fitted in secondary shaft speed
I and II
KEY
1.Sub-gear
2. Main gear
3. Main gear
4. Conical spring washer
5. Retaining circlip
6. Sub-gear
Components
Cambio (parte 1)
COMPONENTS
1. Clutch housing
PORTER 1.3 16V Gear-box
GE - 549
