Steering arm
Removal
Removal
Remove the parts following the numerical order.
KEY:
1. Nut
2. Elastic washer
3. Bolt
4. Steering arm
5. Bushing
To take out the bushing, use the following series
of special tools with a press, as indicated.
Specific tooling
020196Y Clutch guiding tool
0.20228y Rear conical tool to replace the dif-
ferential control pinion bearing
Installation
Installation
Fit the parts following the numerical order.
Steering column PORTER 1.3 16V
SC - 660
