With a hexagonal spanner remove the four Allen
screws to take out the pump.
Remove the O-ring which guarantees the sealing
between the pump body and the valve body.
Remove the oil filter taking out the three Allen
screws.
Smontaggio corpo valvole dal motore elettrico
Removing valve body from the electric motor
Remove the two screws fixing the electric motor to
the hydraulic pump.
Smontaggio valvole
Valve body removal
From the hole uncovered by the oil fitting removal,
it is possible to undo the flow control valve with a
screwdriver.
PORTER 1.3 16V Tipper version
VR - 733
