Diagram
Fitting
1. Fit the rear window wiper motor.
2. Run the motor until it reaches the automatic stop
position.
3. Align the blade with the lower line of the rear
defroster. Tighten the nut.
Removal
1. Remove the rear window wiper and the blade holder arm.
2. Remove the connection cover and the hexagon nut.
3. Remove the washer and the connection gasket.
4. Remove the engine unit.
Check
1. Connect the rear window wiper motor body to
the battery negative (-) terminal.
2. Connect terminal S to the battery negative (-)
terminal.
3. Connect terminal B to the battery positive (+)
terminal. Make sure that rear window wiper is
working.
4. In the operation conditions described above,
disconnect terminal S from the battery negative (-)
terminal. Make sure that the rear window wiper
stops at the automatic stop position.
Starter motor
Start-up system
PORTER 1.3 16V Electrical system
ES - 95
